Bloodhound Mk II Relics

Home

Please contribute if you have photographs of Bloodhound relics.

Ferranti in Manchester

Photos of the Ferranti Cheadle Heath and Wythenshaw offices. Ferranti designed the missile electronics and Launch Control Post. The T86 radar (Firelight) was designed by Ferranti in Edinburgh. Photos courtesy of Jim Reynolds

Click the image for a full size photo.




RAF Museum Cosford

Photos of the Bloodhound section at RAF Museum Cosford. Taken when the equipment had just been put on public display. Photos courtesy of Jim Reynolds

Click the image for a full size photo.







British Aero Museum Kemble

Photos from the museum at Kemble. Make a visit and you are sure to run into several of those involved in the design of Bloodhound, just ask. Photos by Pete Harry

Photos taken on 5th Dec 2011. Click the image for a full size photo.





Royal Air Force Museum Cosford (2)

Bloodhound missile and launcher awaiting work (perhaps). Their condition indicates a long period of storage in the open. Photos courtesy of Paul Lloyd.

Photos taken on 16th Nov 2011. Click the image for a full size photo.

Bloodhound RAF Museum Cosford Bloodhound RAF Museum Cosford Bloodhound RAF Museum Cosford Bloodhound RAF Museum Cosford

Royal Air Force Museum Cosford (1)
The RAF museum at Cosford previously displayed a complete Bloodhound section with Type 86 radar, LCP and missile. The only item on display now is a missile in the Cold War hanger. (Does anyone know where the LCP and T86 radar are kept?)

Photos taken on 16th September 2007. Click the image for a full size photo.

  From Daz Coleman:

"I recall painting this missile to be the Gate Guardian at West Raynham, this missile stands out as it was the only one re sprayed completely gloss green, only the warheads were usually painted gloss green".

Daz served at West Raynham from 1987 -1990 as a painter and finisher.
Missile - Serial Number 1001

Newark Air Museum

Newark Air Museum has a collection of Bloodhound and Thunderbird radars. A Thunderbird missile has also joined the museum's exhibits.

Photos taken on 9th May 2009. Click the image for a full size photo.

Army AD10 radar Radar Type 86 Canberra T17 Radar Type 87
Type 86 Type 86 in desert? Canberra T17* Type 87 (a model of course)

* Electronic Counter Measures (WH863). The nose section was removed from the airframe at RAF Marham in 1990. Seen in the sky over many a Bloodhound site

Imperial War Museum Duxford

Currently a missile on launcher and Launch Control Post (LCP) are on public display. The reminder of the complete Bloodhound section previously on display are now in storage at the rear of the conservation hanger (see below).

Photographs taken on 10th November 2007.
The LCP and Missile at Duxford formed the centre piece for the 2007 Remembrance day service.

Bloodhound MkII Duxford Bloodhound Launch Control Post Duxford Bloodhound Missile Duxford Bloodhound Launcher Duxford Bloodhound Launcher Duxford

Photographs taken on 10th November 2007 - Conservation Hanger.
The remainder of the Bloodhound Section at the rear of the Conservation hanger - Duxford.
Looking for a bit of TLC but at least they are now sheltered from the weather.

Bloodhound Low Loader Duxford Bloodhound Type 86 Radar Duxford

Photographs taken on 29th June 2007 and 5th August 2007.
(The only items now on public display - compare to 5th October 1997 below)

Bloodhound Missile Duxford Bloodhound Missile Duxford Bloodhound Launch Control Post Duxford Bloodhound Launch Control Post (LCP) Duxford
In need of some TLC!
Bloodhound Launcher Duxford Bloodhound Missile Duxford
Can a MOTE guy tell me what I'm looking at?

Photographs taken on 5th October 1997.
The complete missile section was on display in the open on this date.

Bloodhound Relics at North Luffenham

The original question was 'Can anyone confirm if a Type 86 radar and missile (not on launcher) are still on the airfield at North Luffenham'? Yes they can and it's thanks to Dave "Robbo" Robinson for the following pictures taken in February 2008. Dave was a Q-B2-M man at Barkston Heath.

Bloodhound Missile North Luffenham Bloodhound Missile North Luffenham Bloodhound Missile North Luffenham
Bloodhound T86 Radar North Luffenham Bloodhound T86 Radar North Luffenham
Bloodhound LCP North Luffenham Bloodhound LCP North Luffenham Bloodhound LCP North Luffenham

Other Photos of the Bloodhound Relics at North Luffenham.
